Specification
Measuring medium Gas, liquid
Pressure type Gauge pressure(G), Sealed pressure(S)
Pressure range
0~10bar、16bar、25bar、40bar、60bar、160bar、250bar、400bar、
600bar、700bar、1000bar
Power supply 9-32VDC
Output signal 4~20mA 、0~10VDC、0~5VDC、1~5VDC、0.5~4.5 VDC
Nonlinearity
≤0.25% FS (10bar、16bar、25bar)
≤0.05% FS (≥40bar)
Non-repeatability ≤0.1% FS
Accuracy 0.5%FS
Long-term stability 0.15%FS/year
Medium temp -40~+125℃
Operation temp -40~+105℃
Zero temp. drift ≤0.02%FS/℃
FS temp. drift ≤0.02%FS/℃
Response time ≤1ms(10%~90%)
Insulation resistance ≥1000 MΩ/100V
Overpressure 150%FS (1.5 times FS)
Damage pressure 500%FS (5 times FS)
Vibration resistance 5~1000Hz
Shock resistance 50g, 20ms
Process connections G1/4, M14×1.5, or other process connections on request
Materials Wetted parts: 17-4PH, non-wetted parts: stainless steel 304
Ingress protection IP67
Electrical connections Circular connector M12 x 1、L-connector DIN43650;
